| 1.
Formula : Fe3Al2(SiO4)3 |
| 2.
Typical Chemistry ( Mine ) : |
| SiO2 |
37.2% |
Al2O3 |
20.59% |
Fe2O3 |
3.73% |
| FeO |
29.49% |
CaO |
2.02% |
MgO |
6.09% |
| K2O |
0.057% |
Ma2O |
0.034% |
P2O5 |
0.048% |
| TiO2 |
0.25% |
SO3 |
0.022% |
MnO |
0.64% |
|
| 3.
Ore Chemical Composition : |
| Almandine |
Feldspar
& Quartz |
Biotite
& others |
| 93%
min. |
4%
max. |
3%
max. |
|
| 4.
Specific Gravity : |
| 4.02g/cm3
(Result of actual specific gravity test) |
| 5.
Hardness: |
| Modulus
Hardness : 7.0 min. 7.96 max. |
6.
Productive Process Flow :
| Crude
Ore =>
Jaw
Breaking =>Double Rolling
(coarse grain) Double Rolling (fine
grain) =>Wheel
Milling (1st
stage processing : + 8 mesh) =>
Water Scrubbing =>Drying
=> Winnowing =>Classifying
(8x12 mesh ;20x48 mesh ; 48x60 mesh) Sieving
(2nd stage processing : - 60mesh ) Ball Milling
High- intension magnetic separater (0.85T) =>Table
Concentrator=>Dewatering
=>
Drying =>
Classifying =>Classified
Products.
|
|
|
|
|
|
|
| 7.
Product Supply Available : |
| Specifications |
Almandine
Content |
Yearly
Available |
Packing |
| Crude
ore(0-200mm) |
80%
min. |
1,800
mts |
25kgs ;
50kgs ; 1mt ; 2 mts woven plastic with inner
plastic bags or 25 kgs or 50kgs paper
bag packed on pallets at customers
option or as per customers' request
|
| 12x20
mesh |
90%
min. |
5,000
mts |
| 20x26
mesh |
90%
min. |
2,000
mts |
| 26x48
mesh |
93%
min. |
5,000
mts |
| 48x60
mesh |
93%
min. |
1,500
mts |
| 60x200
mesh |
93%
min. |
3,000
mts |
Micropowder |
360#;400#;1000#;1200#etc.
|
|
| 8.
Size of Grain : |
|
8-1. Textile Blasting
(Jeans so on) : |
 |
|
XL Garnet of 30x60 mesh is ideal |
|
media used in the textile (Denim |
|
jeans) by our clients. |
| |
|
8-2. Water Filtration
: |
|
XL Garnet belongs to Almandine type of garnet, it is
very suitable to |
|
be used in Water Filtration . XL Garnet of
2.05x2.45mm ; |
|
1.40x1.55mm ; 1.40x1.70mm ; 0.35x0.45mm ;
0.25x0.30mm ; |
|
0.21x0.28mm ;
0.16x0.25mm are ideal used
as the water filtration |
|
grained layer in multi-media systems by a
lot of clients both |
| domestic
and abroad. |
|
8-3. Sand Blasting : |
|
Requested
distribution of grains
|
|
Tyler
Mesh
|
Sieve
opening
|
Distributing
rate
|
|
|
Under
(mesh)
|
Over
(mesh) |
Under
(µm) |
Over
(µm) |
| Type-a |
/ |
/ |
/ |
2,360 |
0% |
| |
8 |
8 |
2,360 |
1,700 |
5%
max. |
| |
10 |
10 |
1,700 |
850 |
90%
min. |
| |
20 |
20 |
850 |
710 |
5%
max. |
| |
24 |
24 |
710 |
/ |
0% |
| Type-b |
/ |
14 |
/ |
1,180 |
0% |
| |
14 |
20 |
1,180 |
850 |
5%
max. |
| |
20 |
35 |
850 |
420 |
90%
min. |
| |
35 |
48 |
420 |
300 |
5%
max. |
| |
48 |
/ |
300 |
/ |
0% |
| Type-c |
/ |
24 |
/ |
710 |
0% |
| |
24 |
28 |
710 |
600 |
5%
max. |
| |
28 |
48 |
600 |
300 |
90%
min. |
| |
48 |
60 |
300 |
250 |
5%
max. |
| |
60 |
/ |
250 |
/ |
0% |
|
|
8-4. Water Jet
Cutting : |
| 80
W-J-C |
120
W-J-C |
|
US
standard sieve
|
Retained
range
|
US
standard sieve
|
Retained
range
|
|
mesh
|
mm
|
mesh
|
mm
|
| 30 |
0.6 |
0 |
70 |
0.212 |
0-5 |
| 35 |
0.5 |
0-0.5 |
80 |
0.18 |
10-20 |
| 40 |
0.425 |
0-1 |
100 |
0.15 |
25-40 |
| 50 |
0.3 |
10-25 |
120 |
0.125 |
25-40 |
| 60 |
0.25 |
20-40 |
140 |
0.106 |
0-10 |
| 70 |
0.212 |
10-30 |
-140 |
-0.106 |
0-5 |
| 80 |
0.18 |
8-20 |
|
|
|
| 100 |
0.15 |
5-15 |
|
|
|
| -100 |
-0.15 |
0-5 |
|
|
|
|
|
8-5. XL
Garnet's full products of garnet sand:
XL
Garnet’s garnet sand product
|
Garnet sand products
|
|
MM
|
Mesh
|
6/10
|
8/12
|
10/14
|
12/20
|
16/25
|
20/40
|
20/60
|
30/60
|
80
|
100
|
120
|
150
|
220
|
|
3.35
|
6
|
49.94
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2.36
|
8
|
46
|
1.05
|
|
|
|
|
|
|
|
|
|
|
|
|
2.0
|
10
|
4.06
|
17.09
|
|
|
|
|
|
|
|
|
|
|
|
|
1.7
|
12
|
|
59.11
|
6.03
|
0.2
|
|
|
|
|
|
|
|
|
|
|
1.4
|
14
|
|
22.35
|
87.91
|
29.17
|
|
|
|
|
|
|
|
|
|
|
1.18
|
16
|
|
0.4
|
6.06
|
38.96
|
0.4
|
|
|
|
|
|
|
|
|
|
1.0
|
18
|
|
|
|
25.79
|
16.22
|
|
|
|
|
|
|
|
|
|
0.85
|
20
|
| |
